RESULTS OF RESEARCH, CALCULATION AND SELECTION OF VACUUM SUCTION PIPING SYSTEM APPLIED TO AUTOMATIC FABRIC FEEDING MECHANISM OF INDUSTRIAL SEWING MACHINES

Số phát hành: Tạp chí Công nghiệp nông thôn số 57/2025

Từ khóa:
Automatic fabric feeder shock absorber
Tóm tắt
The article publishes the results of research and calculation of vacuum suction chamber installed in the automatic fabric feeding mechanism of industrial sewing machines to confirm that the in-line vacuum damper is a suitable solution to help stabilize the pressure in the mechanism. With the results of mathematical model calculations for the damper, it has been confirmed that the 9-chamber flow path is a suitable choice and it can be used as a in-line vacuum damper in the fabric feeding mechanism of industrial sewing machines.
Tài liệu tham khảo
  1. [1] Công ty may Hoà Thọ, Sáng kiên cải tiến ký thuật, 2024.
  2. [2] Công ty rô-bốt KUKA - CHLB Đức, Nghiên cứu thử nghiệm cơ cấu cấp vải tự động, 2023.
  3. [3] Nguyễn Minh Nhật, “Giáo trình thực tập cơ bản in Offset tờ rời” 2013.
  4. [4] Ray Wai Man Kong, Mingyi Liu, Theodore Kong, Design and Experimental Study of Vacuum Suction Grabbing Technology to Grasp Fabric Piece. 2023
  5. [5] M. Metwally, Effect of in Line Suction Damper Chambers Matrix on the Performance of Vacuum Paper Feeding System, 2015
  6. [6] Emilia Bălan, Liviu Berculescu, Răzvan- [13] George Răcheru, Dorin Vasile Piţigoi, and Lucia Adăscălița. ""Preventive maintenance features specific to offset printing machines"", 2021.
  7. [7] Prof. V. Vasudeva Rao. ""Vacuum Technology and Process Applications by V V Rao"", 2022
  8. [8] Heidelberg (2000). Printmaster QM 46 Technical manual, Germany
  9. [9] Lecturer, Egyptian Armed Forces, Effect of in Line Suction Damper Chambers Matrix on the Performance of Vacuum Paper Feeding System M. Metwally. 2015
  10. [10] R. M. Dixon. et. al. (1968) A Vacuum System for Accumulating Runoff from Infiltrometers. Soil Science Society of America SSSAJ, Vol. 32 No. 1, p. 123-125
  11. [11] Briones, L.et. al. (1994) Wall-climbing robot for inspection in nuclear power plant. IEEE International Conference Robotics and Automation, volume 2. pp 1409-1414
  12. [12] Zhi-Yuan. et. al. (2006) Design and realization of a non-actuated glass-curtain wall- cleaning robot prototype
  13. with dual suction cups. The International Journal of Advanced Manufacturing Technology, Volume 30, Issue 1-2, pp 147-155
  14. S. Ramaswamy (2003) Vacuum Dewatering During Paper Manufacturing International Journal of Drying Technology Volume 21, Issue 4, pp 685-717
  15. [14] K. Lien. and G. Davis. (2008) A novel gripper for limp materials based on lateral Coanda ejectors. CIRP Annals -Manufacturing Technology Volume 57, Issue 1.
  16. [15] Yousef G. et. al. (2014) Vacuum Cavity Parabolic Trough Collector. Proceeding of ASME 2014 International Mechanical Engineering Congress and Exposition Volume 6B: Energy, Canada
  17. [16] S.A. Orszag. et. al. (1993) Renormalization Group Modeling and Turbulence Simulations. Proceeding of the International Conference on Near-Wall Turbulent Flows, Tempe, Arizona, USA
  18. [17] ANSYS Fluent 15.0, Theory Guide (2013) pp 4-11-4-13.
