RESEARCH, DESIGN AND DEVELOPMENT OF A DATA ACQUISITION UNIT FOR A ROOFTOP SOLAR ENERGY SYSTEM

Số phát hành: Tạp chí Công nghiệp nông thôn số 61/2026

Từ khóa:
Arduino Mega 2560 data acquisition unit IoT rooftop solar power performance monitoring.
Tóm tắt
Rooftop solar power systems play a vital role in Vietnam’s Net-Zero target by 2050. However, the lack of automatic monitoring systems remains a significant challenge for early detection of performance degradation. This study designed and fabricated a data acquisition unit based on Arduino Mega 2560 and ESP32. The device integrates multiple sensors to measure solar irradiance (INA219), DC voltage (isolated ES-K12), current (WCS1500), panel temperature (DS18B20), air temperature and humidity (SHT30), wind speed, and particulate matter (PMS5003). Field testing on a 3 kWp system over 3 months showed measurement errors of ±4.5% for irradiance, ±2.8% for voltage and current, and ±0.6°C for temperature. System efficiency ranged from 11.3% to 12.6% under irradiance of 560–985 W/m². The unit displayed data in real-time on HMI, stored on SD card, and transmitted via MQTT. The developed system provides a low-cost, stable, and practical solution for monitoring small-scale rooftop solar systems
Tài liệu tham khảo
  1. 1. International Energy Agency,
  2. Renewables 2024 – Executive Summary.
  3. Paris, France: IEA, 2024
  4. 2. R. Chidembo, J. Francis, and S.
  5. Kativhu, “Rural Households’
  6. Perceptions of the Adoption of Rooftop
  7. Solar Photovoltaics in Vhembe District,South Africa,” Energies, vol. 15, no. 17,
  8. p. 6157, 2022.
  9. 3. T. N. Do, P. J. Burke, K. G. H.
  10. Baldwin, and C. T. Nguyen, “Underlying
  11. drivers and barriers for solar
  12. photovoltaics diffusion: The case of
  13. Vietnam,” Energy Policy, vol. 144, p.
  14. 111561, 2020.
  15. 4. D. C. Jordan and S. R. Kurtz,
  16. “Photovoltaic Degradation Rates—An
  17. Analytical Review,” 2012.
  18. 5. R. J. Mustafa, M. R. Gomaa, M. AlDhaifallah, and H. Rezk, “Environmental
  19. Impacts on the Performance of Solar
  20. Photovoltaic Systems,” Sustainability,
  21. vol. 12, no. 2, p. 608, 2020.
  22. 6. V. Gupta, M. Sharma, R. K.
  23. Pachauri, and K. N. Dinesh Babu,
  24. “Comprehensive review on effect of dust
  25. on solar photovoltaic system and
  26. mitigation techniques,” Solar Energy,
  27. vol. 191, pp. 596–622, 2019.
  28. 7. National Renewable Energy
  29. Laboratory, Sandia National Laboratory,
  30. SunSpec Alliance, and the SunShot
  31. National Laboratory Multiyear
  32. Partnership (SuNLaMP) PV O&M Best
  33. Practices Working Group, Best Practices
  34. for Operation and Maintenance of
  35. Photovoltaic and Energy Storage
  36. Systems; 3rd Edition. Golden, CO, USA:
  37. NREL, 2018.
  38. 8. A. Hamied, A. Mellit, M.
  39. Benghanem, and S. Boubaker, “IoTBased Low-Cost Photovoltaic Monitoring
  40. for a Greenhouse Farm in an Arid
  41. Region,” Energies, vol. 16, no. 9, p. 3860,
  42. 2023.
  43. 9. N. Rouibah, A. El Hammoumi, A.
  44. Bouttout, S. Haddad, S. Oukaci, A.
  45. Limam, and M. Benghanem, “Smart
  46. monitoring of photovoltaic energy
  47. systems: An IoT-based prototype
  48. approach,” Scientific African, vol. 30, p.
  49. e02973, 2025
